Efficient separation of liquid aerosols
Thanks to their compact design and high pressure resistance, the filters can be easily and space-efficiently integrated – ideal for dispensers, compressors, or storage units.
Effective aerosol separation
Finest droplets adhere to fibers, coalesce, and are reliably separated.
Mechanical & chemical-free
Coalescence principle without additives – environmentally friendly and minimizes effort.
Optimized flow
Targeted slowing of the gas flow promotes droplet formation – for maximum separation efficiency.
Highly stable & robust
Pressure-resistant and suitable for high-pressure applications up to 450 bar – for demanding industrial uses.
Easy maintenance
Safe condensate removal: Separated liquid collects in the housing base and can be drained in a controlled manner.
Function of the Coalescing Filters
The pressurized gas flows into the filter inlet and passes through a multilayer filter element made of fine-fiber material. During this process, the finest liquid droplets and aerosols are mechanically separated and collected as condensate.
Separation principle overview:
- Adhesion to fibers: Moist particles stick to the fiber material.
- Coalescence: Small droplets merge to form larger droplets.
- Gravity separation: The formed droplets settle into the filter housing and can be drained.
- Additional solid particle separation: Dust, rust, or abrasion particles are also mechanically retained.
This keeps the gas clean and dry – and your system protected.
Typical Applications at a Glance
Filtering media
Discover & Download
Downloads
Catalogs
Get a quick overview of the entire range of WEH products - clear, compact and as a PDF for download.
Operating Instructions
All information on the safe commissioning and use of our products - including safety instructions and step-by-step instructions.
Certificates
Our products are tested and certified according to international standards. Here you will find all relevant quality and conformity certificates.
Why WEH?
Quality You Can Rely On
Our products are manufactured to the highest standards. At WEH, quality is no coincidence – it’s our standard, ensured by 100% final inspection and certified processes.
Service You Can Rely On
By choosing a WEH® product, you’ve chosen long-lasting quality. And our service ensures it stays that way. Whether maintenance, inspection, repair, or original spare parts – our experienced team is committed to maximum safety, efficiency, and preserving the value of your equipment.
Fast and Helpful Support
Questions about application, technology, or spare parts? Our technical support team is here for you – direct, competent, and without detours. Personally available and globally reliable.
